Kev kub ceev WJ-8 Rail Fastening System
WJ-8 rail fastening system (tseem hu ua WJ-8 elastic fastener) yog tsim rau rails nrog lub ntsuas ntawm 1435 hli thiab ceev ntawm 60 kg / m. Lub German neeg nrog caij nplooj siab kab fastener system cov kev specifications coj mus rau txoj kev loj hlob ntawm WJ-8 rail fastening system, ib tug ballastless khiav ...
- Khoom Taw qhia
WJ-8 rail fastening system (tseem hu ua WJ-8 elastic fastener) yog tsim rau rails nrog lub ntsuas ntawm 1435 hli thiab ceev ntawm 60 kg / m. Lub German neeg nrog caij nplooj siab kab fastener system cov kev specifications coj mus rau txoj kev loj hlob ntawm WJ-8 rail fastening system, ib tug ballastless khiav fastener system. Lub kaw lus fastener, uas yog ib qho elastic uas tsis yog-separable fastener qauv nrog rail pads, tau tsim nyob rau hauv cov kev txwv ntawm cov thawj phaj raws li zoo raws li qhov ntev thiab qhov chaw ntawm ob-block ballastless khiav bearing zawj.
Daim ntawv thov Scope:
WJ-8 elastic rail clamp fastener system yog tsim nyog rau CRTSII ballless lem nrog ib tug qag load ntawm 170 KN (xav tias ib tug 10% nce nyob rau hauv qag load) thiab cov neeg nrog caij nplooj siab kab nrog lub siab tshaj plaws qag ceev ntawm 350 km / h. WJ-8 fastener system feem ntau yog zoo thiab tau siv nyob rau hauv ntau qhov chaw.
| Lub sij hawm xa tuaj | Hauv 20-40 hnub ua haujlwm, nyob ntawm qhov ntau |
| Chaw thau khoom chaw nres nkoj | Shanghai, Tianjin, Qingdao |
| Muaj peev xwm | 5000+pcs / Ib Hlis |
| Ntim Cov Lus Qhia | Txhua lub hnab ntim tsawg dua 25KG. Fumigation -dawb pallet. Cov neeg siv khoom tuaj yeem hais qhia tus qauv |
Fastener Composition
●WJ-8 fasteners yog tsim los ntawm kauv spikes, flat washers, caij nplooj ntoos hlav tuav, insulating gauge blocks, gauge baffles, rail pads, hlau pads, elastic pads nyob rau hauv lub hlau pads, thiab embedded tes tsho. Txhawm rau ua kom tau raws li qhov xav tau ntawm kev hloov qhov siab, lawv kuj suav nrog cov tsheb ciav hlau zoo-tuning pads thiab hlau ncoo qhov siab hloov pauv.
● Muaj ob hom kev caij nplooj ntoos hlav, uas yogW1 caij nplooj ntoos hlav bar(inch 14 mm) thiabX2 lub caij nplooj ntoos hlav bar(inch 13 mm). X2 lub caij nplooj ntoos hlav tuav yog siv thaum siv cov hlua khi me me ntawm cov txuas hniav.
● Muaj ob hom gauge baffles, uas yog gauge baffles rau feem dav thiab sib koom gauge baffles rau clamping daim hlau.
●Elastic ncoo nyob rau hauv cov ntaub qhwv hlau muab faib ua ob hom, A thiab B (ob leeg nrog lub thickness ntawm 12 hli). Class A elastic pads yog siv rau siab - kev tsheb ciav hlau ceev uas tseem xav txog kev thauj khoom, thiab Class B elastic pads yog siv rau siab - kev tsheb ciav hlau ceev uas tsuas yog khiav tsheb thauj neeg.
●Spiral spikes muab faib ua ob hom: s2 thiab s3. Thaum lub fastener ntsia tau rau hauv ib txwm lub xeev lossis txoj kev tsheb ciav hlau qhov siab hloov tsis ntau dua 15 hli, s2 hom kauv ntsia hlau yog siv, thiab thaum qhov kev hloov qhov siab siab dua 15 hli, s3 hom kauv ntsia hlau yog siv.
● Ob hom kev tsheb ciav hlau:
① WJ-8A hom fasteners siv Class A elastic pads (zoo li qub stiffness ntawm 35 ± 5kN / mm), uas yog haum rau cov neeg nrog caij nplooj siab kab khiav hauj lwm tej yam kev mob nrog ib tug siab tshaj plaws ceev ntawm 250km / h rau freight thiab cargo;
② WJ-8B hom fasteners siv Class B elastic pads (zoo li qub stiffness ntawm 23 ± 3kN / mm), uas yog haum rau nteg ob-thaiv ballastless lem nrog ib tug siab tshaj plaws ceev ntawm 350km / h rau cov neeg nrog caij nplooj siab kab;
③ WJ-8C hom fasteners siv Class B elastic pads (zoo li qub stiffness ntawm 23 ± 3kN / mm), uas yog haum rau tso CRTS II hom khiav daim hlau nrog ib tug siab tshaj plaws ceev ntawm 350km / h rau cov neeg nrog caij nplooj siab kab.
Main TechnicalKev xav tau
① Ib qho ntawm cov roj tiv thaiv yuav tsum tau ua kom ntseeg tau hauv cov khoom siv, thiab cov roj ua haujlwm yuav tsum ua raws li cov cai.
② Kev sib koom ua ke gauge baffles thiab insulating gauge blocks yuav tsum tau siv ntawm lub phaj clamping.
③ Caij nplooj ntoos hlav bar installation txheej txheem: Lub puab tsaig sab hauv qab ntawm lub puab tsaig nruab nrab ntawm lub caij nplooj ntoos hlav bar yuav tsum tsis txhob hu rau lub insulating gauge thaiv, thiab qhov sib txawv ntawm ob yuav tsum tsis txhob ntau tshaj 0.5mm los yog thaum siv ib tug torque ciaj ntswj los xyuas kom meej lub torque ntawm lub kauv spike, Wl hom caij nplooj ntoos hlav bar yog 130 ~ 170N2 ·m 1, thiab lub caij nplooj ntoos hlav X.
④ Caij nplooj ntoos hlav bar txij nkawm tus qauv: Lub puab tsaig pem hauv ntej kawg ntawm lub puab tsaig nruab nrab ntawm lub caij nplooj ntoos hlav bar yuav tsum tsis txhob hu rau lub insulating gauge thaiv, thiab qhov sib txawv ntawm ob yuav tsum tsis txhob ntau tshaj 1 hli; los yog thaum siv lub torque ciaj ntswj los xyuas qhov torque ntawm cov ntsia hlau loj, W1 hom caij nplooj ntoos hlav bar yog 130 ~ 170N·m, thiab X2 hom caij nplooj ntoos hlav bar yog 90 ~ 120N·m.
⑤ Lub gauge baffle yuav tsum nyob ze rau lub xub pwg nyom ntawm cov kabmob rail groove, thiab qhov sib txawv yuav tsum tsis txhob ntau tshaj 1 hli; Qhov sib npaug ntawm qhov sib txawv ntawm txoj kev tsheb ciav hlau thiab lub ntsuas hluav taws xob thaiv, thiab lub ntsuas hluav taws xob insulating thiab cov hlau pad lub xub pwg yuav tsum tsis txhob ntau tshaj 1 hli.
⑥ Rail sab laug thiab txoj cai hloov txoj hauj lwm: ± 5mm.
⑦ Kho qhov siab: 4 ~ +26mm.
Khoom Specifications
|
Serial tooj |
Lub npe |
Ntau |
Khoom siv |
Loj los yog ntim |
Lus hais |
|
1 |
Kauv ntsia hlau |
2 |
High quality carbon steel los yog alloy steel |
1.50 kg ib |
Hom S2 feem ntau yog siv, thiab S3 hom yog siv thaum qhov siab siab tshaj 15 hli. |
|
|
|
|
|
|
|
|
2 |
Flat Washers |
2 |
Q235-A |
0, 138kg |
-- |
|
3 |
W1 hom elastic clip |
2 |
60 Si2MnA |
1, 44kg |
Tshooj dav siv hom W1, ib qho elastic rail clip buckle siab yog ntau dua 9kN, thiab elastic stroke yog 14 hli. |
|
|
X2 hom elastic clip |
|
|
1.28 kg ib |
Hom X2 yog siv rau thaj tsam me me. Ib lub caij nplooj ntoos hlav buckle muaj lub siab ntawm 6kN thiab stroke ntawm 12 hli. |
|
4 |
WJ8 insulation thaiv |
2 |
Cov iav fiber reinforced nylon PA66 |
79,0cm 3 |
Hom I, siv nyob rau hauv qhov chaw dav dav. |
|
|
|
|
|
73.0cm3 ua |
Hom II, siv rau hauv kev sib koom ua ke rail. |
|
5 |
WJ 8 gauge |
2 |
Cov iav fiber reinforced nylon PA66 |
718cm 3 |
Kev teeb tsa ib txwm tsis muaj . 7, xaiv tus lej sib txawv raws li kev ntsuas ntsuas. Joint gauge baffle ntawm rail joint |
|
|
WJ8 Joint gauge baffle |
|
|
|
|
|
6 |
WJ 8 pad |
1 |
Ntuj roj hmab los yog hluavtaws roj hmab |
140 cm3 |
Xaiv ib qho ntawm lawv raws li cov kev cai tshwj xeeb ntawm kab tsis kam. Cov phaj rov qab sib xyaw yog tsim los ntawm vulcanizing 1.2 hli tuab 1Cr18Ni9Ti stainless hlau phaj thiab roj hmab. Tsis txhob siv cov roj hmab rov qab |
|
|
|
|
|
|
|
|
|
WJ 8 composite pad |
|
roj hmab |
110 cm3 |
|
|
|
|
|
stainless hlau |
0.25 kg ib |
|
|
7 |
WJ8 rail pad |
1 |
QT450-10 |
6, 80kg |
-- |
|
8 |
WJ8 hlau rail pad nyob rau hauv lub rail pad |
1 |
Thermoplastic elastomer (ua npuas ncauj) |
540cm 3 |
Lub zog zoo li qub ntawm A- hom ncoo yog 30 ~ 40 kN / mm, uas yog tsim rau 250 km / h cov neeg caij tsheb tshwj xeeb (xav txog kev thauj khoom thauj); |
|
|
|
|
|
|
Lub zog zoo li qub ntawm B- hom ncoo yog 20 ~ 26 kN / mm, uas yog tsim rau 350 km / h cov neeg caij tsheb tshwj xeeb; dynamic thiab static stiffness piv tsis ntau tshaj 2.0. |
|
9 |
Ua ntej-embedded casing D1 |
2 |
Cov iav fiber reinforced nylon PA66 |
115cm 3 |
Lub rub- tawm qhov kev tawm tsam ntawm cov embedded bushing nyob rau hauv lub sleeper tsis tsawg tshaj li 60kN. |
|
10 |
WJ8 nyob rau hauv -rail fine{2}}tuning pad |
1 |
Polyethylene txhaj tshuaj molding |
25cm3 / hli |
Raws li qhov xwm txheej tshwj xeeb |
|
|
|
|
|
|
|
|
11 |
WJ8 hlau rail pad down lub siab ncoo |
2 |
Polyethylene txhaj tshuaj molding |
720cm3 / 10 hli |
Raws li qhov xwm txheej tshwj xeeb |
Kev Xav Tau
|
Fastener hom |
WJ-8 hom fastener |
||
|
Taxonomy |
Nrog hlau rail ncoo (thickness 16mm) |
||
|
Nrog rau sab nraud quab yuam |
Sustained los ntawm lub xub pwg nyom |
||
|
Kev sib txuas nrog lub hauv paus |
Embedded yas casing |
||
|
Embedded tus tswv cuab rub- tawm tsis kam |
Tsis pub tsawg tshaj 60kN |
||
|
Buckle |
Hom ntawm |
W1 yam |
Hom X 2 |
|
|
Buckle siab |
>9kn ua |
6kn ua |
|
|
Ntaus |
14mm ib |
12 hli |
|
|
Txoj kev fastening |
Bolt fastening |
|
|
|
Tightening torque |
Txog 160 Nm |
Txog 110Nm |
|
Rail longitudinal kuj |
>9kn ua |
4kn ua |
|
|
hlau rail ncoo fastening torque |
-- |
||
|
Elastic cushion |
Kev teeb tsa |
Ib txheej cushion (rubber pad lossis composite rubber ncoo) yog teem rau hauv qab ntawm txoj kev tsheb ciav hlau, thiab txheej txheej cushion elastic (thermoplastic elastomer foaming pad) yog teem rau hauv qab hlau rail pad phaj. |
|
|
|
qhov loj |
Chav Kawm A |
Chav B |
|
|
|
Hauv qab rail roj hmab ncoo: 175 × 156 × 4 |
|
|
|
|
rail ncoo hauv qab hlau rail ncoo 285 × 150 × 12 |
|
|
Hauv qab -arc cushion stiffness |
>300 kN / hli |
||
|
Sub{0}} txheej cushion stiffness |
30-40kN / hli |
20 ~ 30kN / hli |
|
|
Rail qhov siab |
High rail nto |
208 |
|
|
|
Kho tus nqi |
30 hli |
|
|
|
Txoj kev hloov kho |
Los ntawm kev kho qhov siab ntawm lub ncoo ntawm txoj kev tsheb ciav hlau thiab cov hlau rail ncoo kom ua tiav 10 hli hloov; padding lub ncoo ntawm lub sleeper bearing zawj kom ua tiav 20mm hloov. Lub filling ncoo tuaj yeem hloov kho steplessly. |
|
|
ntsuas |
Kho tus nqi |
± 10 hli |
|
|
|
Txoj kev hloov kho |
Nws yog pom tau los ntawm kev hloov lub gauge baffles ntawm txawv specifications. |
|
|
|
Kev kho theem |
Kev hloov kho, qib 1mm |
|
|
Rail kev kho mob |
Feem ntau, thaum qhov kev ntsuas dav dav hloov pauv loj, hloov qhov sib koom ua ke gauge baffle. |
||
|
Muaj feem xyuam rau ballastless khiav |
Armless khiav qauv |
||
|
Daim duab naj npawb thiab qauv |
Kev Tshawb Fawb Kab 0604, Science thiab Technology Base [2007] 207 |
||
|
Daim ntawv thov mob |
250 km / h |
350km / h neeg caij tsheb kab |
|
Kev sib piv ntawm WJ-7 Thiab WJ-8 Rail Fastening System
|
Serial tooj |
qhov project |
Kev ua tau zoo |
|
|
|
|
WJ-7 fastener |
WJ-8 hom fastener |
|
1 |
Haum rau hom kev tsheb ciav hlau |
Tuam Tshoj 60kg / m rail |
|
|
2 |
ntsuas |
14 35mm |
|
|
3 |
Taug qab txoj kab nqes |
A 1:40 rail hauv qab nqes hav yog muab tso rau ntawm cov hlau rail ncoo. |
A 1:40 rail hauv qab txoj kab nqes yog muab tso rau ntawm lub txaj pw lossis lub rooj tsavxwm. |
|
4 |
Rail longitudinal kuj |
Feem ntau, txhua pawg fasteners loj dua 9kN; rau qhov me me tsis kam, txhua pawg fasteners yog li 4kN. |
|
|
5 |
System yooj |
Lub zog zoo li qub ntawm A- hom tsheb ciav hlau yog 30 ~ 40kN / hli, uas yog tsim rau 250km / h cov neeg caij tsheb tshwj xeeb (xav txog kev thauj khoom thauj); qhov ruaj khov zoo li qub ntawm B- hom rail ncoo yog 20 ~ 30kN / mm, uas yog haum rau 350km / h cov neeg caij tsheb kab; |
|
|
6 |
Dynamic thiab static stiffness ratio |
Tsis ntau tshaj 2.0. |
Tsis ntau tshaj 1.5. |
|
7 |
Kev ua haujlwm qaug zog |
Lub kaw lus fastener raug kuaj raws li EN 13146-4 thaum qhov siab nce 30 hli. Tom qab 3 lab lub voj voog thauj khoom, cov khoom tsis raug puas, qhov ntsuas qhov ntev yog tsawg dua 6 hli, thiab lub buckle siab, qhov ntev ntawm txoj kev tsheb ciav hlau thiab cov kev sib tw zoo li qub ntawm cov tsheb ciav hlau sib koom ua tau raws li cov cai hauv qab no. : buckle siab hloov Tsawg dua lossis sib npaug li 20%; rail longitudinal tsis kam hloov Tsawg dua lossis sib npaug li 20%; node static stiffness hloov tsawg dua los yog sib npaug li 25%. |
|
|
8 |
Rwb thaiv tsev tsis kam |
Lub kaw lus fastener raug kuaj raws li EN13146-5. Lub rwb thaiv tsev tiv thaiv ntawm ob txoj hlua yog ntau dua 3 Ω·km, thiab ua tau raws li qhov yuav tsum tau ua ntawm lub voj voog khiav rau nws cov rwb thaiv tsev. |
|
|
9 |
Ib puag ncig hnyav |
Lub kaw lus fastener tuaj yeem ua tiav tiav nrog cov cuab yeej siv phau ntawv disassembly tom qab 300h ntsev tsuag tshuaj ntsuam tau piav qhia hauv EN13146-6. |
|
|
10 |
Rail sab laug thiab txoj cai txoj hauj lwm hloov |
Kev hloov ntawm sab laug thiab sab xis txoj hauj lwm ntawm ib leeg -strand rail: -6 ~ +6mm; gauge hloov kho: -12 ~ +12mm, tsis tu ncua stepless hloov. |
Kev hloov ntawm sab laug thiab sab xis txoj hauj lwm ntawm ib leeg -strand rail: -5 rau +5 hli; qhov ntsuas kev hloov kho: -10 rau +10 hli, thiab qib kev hloov kho yog 1 hli. |
|
11 |
Rail qhov siab txoj hauj lwm hloov |
Rail qhov siab hloov txoj hauj lwm: 30mm; |
|
|
12 |
Buckle siab thiab ntau yam |
Feem ntau siv elastic rail clips (W1 hom): ib qho elastic rail clip buckle siab yog ntau dua 9kN, thiab elastic stroke yog 14 hli; me me elastic rail clip (X2 hom): ib qho elastic rail clip buckle siab yog 6kN, thiab elastic stroke yog 12 hli. |
|
|
13 |
Rub- tawm qhov tsis kam ntawm cov pob zeb hauv cov neeg pw tsaug zog |
Tsis pub tsawg tshaj 100kN. |
Tsis pub tsawg tshaj 60kN. |
Khoom Zoo
